Felicity Solar 2,250 W Wi-Fi Solar Micro-Inverter
Felicity Solar 2,250 W Wi-Fi Solar Micro-Inverter
Introducing the Felicity Solar X-RAY-BDM2250W Inverter, a cutting-edge solution for your solar energy needs. With an optional WiFi dongle and a maximum recommended PV power of 750x4W, this inverter ensures optimal performance and connectivity. Explore its advanced features to enhance your solar power system.
Key Features
- AC Output Cable
- WiFi Dongle (optional)
- LED display
- DC input (+)
- DC input (-)
Specifications
Electrical
| Power Factor | >0.99 (at full load) |
| WiFi Frequency band | 2.412GHz-2.472GHz |
| WIFI Dongle | Optional |
| WIFI Transmitting Power | 802.11b:+17dBm+1.5dBm@11Mbps |
| Max Recommended PV Power (W) | 750x4 |
| Max DC Open Circuit Voltage (VDC) | 60 |
| Max DC Input Current (Adc) | 20 x 4 |
| MPPT Tracking Range (VDC) | 22-55 |
| Rated AC Output Power (W) | 2250 |
| Rated AC Output Current (Aac) | 9.78 |
| Nominal Power Grid Frequency (HZ) | 50/60 |
| THD (At Rated Power) | <5% |
Environmental
| Environment Temperature | -40℃ ~ +65℃ |
| Protective Class | Ip66/Ip67 |
Certifications: FCC Compliance
FAQs
What are the main performance specifications of the X-RAY-BDM2250W inverter?
The X-RAY-BDM2250W inverter has a rated AC output power of 2250W and a rated AC output current of 9.78A. It operates with a nominal power grid frequency of 50/60Hz and maintains a power factor greater than 0.99 at full load.
Is the X-RAY-BDM2250W inverter compatible with my solar panel setup?
The inverter is compatible with solar panel setups that have a maximum recommended PV power of 750W per panel, up to four panels. It supports a maximum DC open circuit voltage of 60V and a maximum DC input current of 20A per input.
What are the physical specifications of the X-RAY-BDM2250W inverter?
The X-RAY-BDM2250W inverter is designed with a protective class of IP66/IP67, ensuring it is dust-tight and protected against powerful water jets and temporary immersion.
What are the installation requirements for the X-RAY-BDM2250W inverter?
The inverter should be installed in an environment with temperatures ranging from -40°C to +65°C. It is important to ensure proper ventilation and secure mounting to maintain optimal performance.
