Voltronic Power AXPERT-MAX-III-11KW
Axpert MAX III 11KW
Dhs. 1.00
Skip to product information
Voltronic Power AXPERT-MAX-III-11KW
Dhs. 1.00
Voltronic Power AXPERT-MAX-III-11KW, available in 2 ratings, Axpert MAX III 11KW to Axpert MAX III 12KW. Each rating is a different machine with its own figures. Pick the one that matches your system below, then select it in the options above.
True of every rating
- Keeps 93% of what the panels make
- Manufacturer Warranty manufacturer warranty
Choose your rating
Axpert MAX III 11KW
Model AXPERT-MAX-III-11KW. Full specifications are listed below.
Axpert MAX III 12KW
Model AXPERT-MAX-III-12KW. Full specifications are listed below.
Full specifications shared across all 2 ratings
| Parallel Capability | YES, 6 units |
| Selectable Voltage Range (V) | 170-280 VAC (For Personal Computers) |
| AC Voltage Regulation (%) | 230VAC ± 5% |
| Max Efficiency (%) | 93 |
| Standby Power (W) | 75 |
| Max PV Array Power (W) | 12000W (6000W x 2) |
| Max Charge Current (A) | 150 |
| Communication Interface | USB/RS232/RS485/Wifi/Dry-contact |
| Safety Standards | IEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, 61000-3-12 |
| Net Weight (kg) | 28.5 |
| Relative Humidity (%) | 5% to 95% |
| Operating Temperature (°C) | -10°C to 50°C |
| Storage Temperature Range (°C) | -15°C to 60°C |
| Dimensions (mm) | 432.4 x 687 x 176.3 |
