Voltronic Power Galleon One RT
Voltronic Power Galleon One RT
The Galleon One RT by Voltronic Power is a cutting-edge online UPS designed to deliver reliable power protection. With a wide range of nominal voltage options and precise voltage regulation, it ensures your critical systems remain operational under any conditions. Ideal for data centers, telecommunications, and industrial applications, the Galleon One RT provides seamless power backup and protection against voltage fluctuations.
Key Features
- True double-conversion
- Output power factor 1
- Built-in 2.8” touch LCD for — Built-in 2.8” touch LCD for comprehensive UPS status
- Output voltage regulation < 1%
- 50Hz/60Hz frequency converter mode
- Programmable power management outlets
- Hot swappable battery design
- ECO mode energy saving
- Provides overload, battery cut-off protection — Provides overload, battery cut-off protection and surge immunity by MOV for full time equipment protection
- High power factor charger up — High power factor charger up to 8A/12A capacity with very low ripple current when charging battery
- Low input THDi to reduce — Low input THDi to reduce power system pollution
- Adjustable charging current via LCD — Adjustable charging current via LCD panel
- Optional HID Power Device USB — Optional HID Power Device USB Port
Specifications
Electrical
| Nominal Voltage | 100/110/115/120/127 VAC or 200/208/220/230/240 VAC / 208/220/230/240 VAC |
| Voltage Range | 85-150 VAC ± 5% or 110-300 VAC ± 5% @ 50% load / 110-300VAC ± 3% @ 50% load; 176-300VAC ± 3% @ 100% load |
| Frequency Range | 40 Hz ~ 70 Hz / 46~54 Hz or 56~64 Hz |
| Power Factor | > 0.99 @ nominal voltage (100% load) / ≥ 0.99 @ full load |
| Output Voltage | 100*/110*/115*/120*/127 VAC or 200*/208/220/230/240 VAC / 208*/220/230/240 VAC |
| AC Voltage Regulation | ± 1% |
| Frequency Range (Synchronized Range) | 57 ~ 63 Hz or 47 ~ 53 Hz / 46~54 Hz or 56~64 Hz |
| Waveform (Batt. Mode) | Pure Sinewave |
| AC Mode | ≥ 89% @ full charged battery / 94% |
| Battery Type | 12 V / 9 Ah / 7 Ah |
| Numbers | 2 / 3 / 4 / 6 / 16 |
| Charging Current | 2A / 1.0A |
Mechanical
| Dimension, D x W x H (mm) | 410 x 438 x 88 / 510 x 438 x 88 / 630 x 438 x 88 / 610 x 438 x 88 [2U] |
| Net Weight (kg) | 11.6 / 14.1 / 15.5 / 19.5 / 17 / 20 |
| Weight | 11.6 / 14.1 / 15.5 / 19.5 / 17 / 20 |
Environmental
| Humidity | 20-90 % RH @ 0-40°C (non-condensing) |
| Noise Level | Less than 50dB @ 1 Meter / Less than 55dB @ 1 Meter |
Certifications: cTUVus (comply to UL1778), FCC
FAQs
What are the main performance specifications of the Galleon One RT?
The Galleon One RT offers a power factor greater than 0.99 at nominal voltage with an efficiency of ≥ 89% in AC mode and ≥ 88% in battery mode. It supports a nominal voltage range of 100/110/115/120/127 VAC or 200/208/220/230/240 VAC.
Is the Galleon One RT compatible with different battery types or solar panels?
The Galleon One RT uses two 12 V / 9 Ah batteries. It is primarily designed for grid power and does not directly support solar panels.
What are the physical specifications of the Galleon One RT?
The Galleon One RT has dimensions of 410 x 438 x 88 mm and a net weight of 11.6 kg. It does not have an IP rating, indicating it should be used in controlled environments.
What are the installation requirements for the Galleon One RT?
The Galleon One RT should be installed in a well-ventilated area with stable temperature and humidity levels. Ensure it is placed on a stable surface to support its weight of 11.6 kg.
What warranty is provided with the Galleon One RT?
Voltronic Power typically offers a standard warranty for their products, but specific terms for the Galleon One RT should be confirmed with the retailer or distributor.
What certifications and standards does the Galleon One RT comply with?
The Galleon One RT is certified with cTUVus, complying with UL1778 standards, and also meets FCC regulations.
What are the operating conditions for the Galleon One RT?
The Galleon One RT operates efficiently within a frequency range of 40 Hz to 70 Hz. It should be used in environments with controlled temperature and humidity to ensure optimal performance.
What are the key features and benefits of the Galleon One RT?
Key features of the Galleon One RT include its high efficiency, pure sinewave output in battery mode, and robust voltage regulation of ± 1%. These features ensure reliable power supply and protection for sensitive equipment.
