Voltronic Power Galleon III Tower RT 1-3K
Voltronic Power Galleon III Tower RT 1-3K
The Voltronic Power Galleon III Tower RT 1-3K is a robust uninterruptible power supply designed to ensure continuous power delivery. Equipped with USB and RS-232 communication ports, and an optional SNMP intelligent slot, it offers versatile connectivity and advanced protection. Ideal for safeguarding critical systems in data centers, telecommunications, and network environments, ensuring uninterrupted operation and data integrity.
Key Features
- N/A
- Hot-swappable battery design
- Advanced communication and monitoring options
- Programmable management outlets
Specifications
Electrical
| AC input | N/A |
| USB communication port | Yes |
| RS-232 communication port | Yes |
| SNMP intelligent slot | Optional |
| Communication Ports | USB port / RS-232 port / Intelligent slot |
| External Battery Connection | Voltage ≥ 1.25 x battery voltage/set / Current ≥ 50A |
| Nominal Voltage | 200/208/220/230/240 VAC |
| Input Voltage Range | 110 – 300 VAC / 160 – 300 VAC |
| Frequency Range | 40 Hz ~ 70 Hz |
| Power Factor | ≥ 0.99 @ nominal voltage (100% load) |
| THD | ≤ 5% @ nominal voltage (100% load) |
| Output Voltage | 200/208/220/230/240 VAC |
| AC Voltage Regulation (Batt. Mode) | ± 1% |
| Frequency Range (Synchronized Range) | 47 ~ 53 Hz or 57 ~ 63 Hz |
| Frequency Range (Batt. Mode) | 50 Hz ± 1 Hz / 60Hz ± 0.1 Hz |
| Current Crest Ratio | 3:1 |
| Harmonic Distortion | ≤ 2 % THD (Linear Load) ; ≤ 5 % THD (Non-linear Load) |
| Transfer Time | 0 ms |
| Waveform (Batt. Mode) | Pure Sinewave |
| ECO mode @ full charged battery | 96% / 97% |
| AC Mode @ full charged battery | 92% / 93% / 94% |
| Battery Type | 12 V / 9 Ah / 7 Ah |
| Numbers | 2 / 3 / 4 / 6 |
| Typical Recharge Time | 4 hours recover to 90% capacity for internal battery |
| Charging Current (CC) | 1.5A |
| Charging Voltage (FV) | 27.4VDC ± 1% / 41.0VDC ± 1% / 54.8VDC ± 1% / 82.2VDC ± 1% |
| EMC/Safety | CE (EMC: EN62040-2 C2) |
Mechanical
| Dimension, D x W x H (mm) | 282 x 145 x 220 / 397 x 145 x 220 / 421 x 190 x 318 |
| Net Weight (kgs) | 9.8 / 11.4 / 13.8 / 17 / 22.5 / 26.2 |
| Weight | 9.8 / 11.4 / 13.8 / 17 / 22.5 / 26.2 |
Environmental
| Modem/Phone/Network surge protection | Yes |
| Ambient Temperature Range | 0°C to 40°C |
| Altitude | 1000m |
| Humidity | 20-90 % RH @ 0- 50°C (non-condensing) |
| Noise Level | Less than 50dB(A) @ 1 Meter with Fan speed control |
Certifications: CE
FAQs
What are the main performance specifications of the Galleon III Tower RT 1-3K?
The Galleon III Tower RT 1-3K is designed to provide reliable power with high efficiency. It supports a wide range of input voltages and offers robust surge protection for modem, phone, and network connections.
Is the Galleon III Tower RT 1-3K compatible with different battery types or solar panels?
The UPS is compatible with external batteries, requiring a voltage of at least 1.25 times the battery voltage per set. However, it does not directly support solar panel connections.
What are the physical specifications of the Galleon III Tower RT 1-3K?
The physical dimensions and weight of the Galleon III Tower RT 1-3K are not specified in the provided information. Please refer to the product manual for detailed specifications.
What are the installation requirements for the Galleon III Tower RT 1-3K?
Installation requires a stable environment with an altitude of up to 1000 meters and an ambient temperature range of 0°C to 40°C. Ensure proper ventilation and secure mounting.
What warranty information is available for the Galleon III Tower RT 1-3K?
Warranty details are not specified in the provided information. It is recommended to contact Voltronic Power or your supplier for specific warranty terms.
What certifications and standards does the Galleon III Tower RT 1-3K meet?
The Galleon III Tower RT 1-3K does not list specific certifications or standards in the provided information.
What are the operating conditions for the Galleon III Tower RT 1-3K?
The UPS operates efficiently within an ambient temperature range of 0°C to 40°C and is suitable for altitudes up to 1000 meters.
What are the key features and benefits of the Galleon III Tower RT 1-3K?
Key features include USB and RS-232 communication ports, optional SNMP intelligent slot, and surge protection for modem, phone, and network connections, ensuring reliable and versatile power management.
