Felicity Solar 51.2 V LiFePO4 Battery (FLB48205WG1)
Dhs. 1.00
Skip to product information
Felicity Solar 51.2 V LiFePO4 Battery (FLB48205WG1)
Dhs. 1.00
The Felicity FLB48205WG1 is a lifepo4 battery pack with a 51.2V nominal bus, Cycles (25°C +2°C,0.5C/0.5C,90%DOD, 70 rated, 86.5KG shipped. Every figure on this page is taken from the manufacturer's datasheet for the FLB48205WG1.
Specifications
Electrical
| Battery Type | LiFePO4 |
| Nominal Voltage | 51.2V |
| Operating Voltage | 44.8~57.6V |
| Depth of Discharge (DOD) | >95% |
| Protection | Built-in smart BMS, Breaker, Fuse |
| Max. Continuous Charge/Discharge Current | 150A |
| Peak Charge/Discharge Current (15s) | 200A |
| Scalability | Max. 32 pcs in Parallel(336kWh) |
| Cycle Life | Cycles (25°C +2°C,0.5C/0.5C,90%DOD, 70 |
Mechanical
| Installation | Wall-Mounted / Floor-Mounted |
| Product Weight | 86.5KG |
| Package Weight | 106KG |
| Product Dimension | 683x450x258 mm |
| Package Dimension | 778x548x438 mm |
Environmental
| Working Temperature Range | Charge: 0°C~+55 °C |
| Humidity | 5%~95% |
| Altitude | <2000m |
