Voltronic Power Axpert MAX TRI 12K
Voltronic Power Axpert MAX TRI 12K
The Axpert MAX TRI by Voltronic Power is a high-performance inverter designed to meet demanding power needs. With a robust capacity of 12000VA/12000W and the ability to operate in parallel with up to 6 units, this inverter ensures reliable and efficient power management. Ideal for residential and commercial applications, the Axpert MAX TRI is perfect for powering personal computers, home appliances, and small industrial equipment.
Key Features
- Dual inputs and three outputs — Dual inputs and three outputs for smart energy management
- Status indication with RGB lights
- Upgrade maximum PV current to — Upgrade maximum PV current to 60A for 12K model
- Built-in Wi-Fi for mobile monitoring — Built-in Wi-Fi for mobile monitoring and OTA firmware
- Supports USB (Type-C) On-the-Go function — Supports USB (Type-C) On-the-Go function for exporting log and firmware upgrade
- Reserved communication port for BMS — Reserved communication port for BMS (RS485, CAN-BUS or RS232)
- Battery independent design
- Configurable AC/PV output usage timer — Configurable AC/PV output usage timer and prioritization
- Built-in external CT sensor to — Built-in external CT sensor to guarantee 100% self-consumption
- Built-in anti-dust kit
- Parallel operation with 6 units
Specifications
Electrical
| Rated Output Power (VA) | 12000VA |
| Rated Output Power (W) | 12000W |
| Parallel Capability | YES, 6 units |
| Voltage | 230 VAC |
| Selectable Voltage Range | 90-280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| AC Voltage Regulation (Batt. Mode) | 230 VAC ± 5% |
| Surge Power | 24000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 63 VDC |
| Solar Charger Type | MPPT |
| Maximum PV Array Power | 18000W (Max. 12000W per tracker) |
| MPPT Range @ Operating Voltage | 90 – 450 VDC |
| Maximum PV Array Open Circuit Voltage | 500 VDC |
| Maximum PV Input Current | 40A/27A (MAX 60A) |
| Maximum Solar Charge Current | 200 A |
| Maximum AC Charge Current | 200 A |
| Maximum Charge Current | 200 A |
| Compliance Safety | IEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, 61000-3-12 |
Mechanical
| Dimension, D x W x H (mm) | 147.4 x 432.5 x 553.6 |
| Net Weight (kg) | 18.8 |
| Communication Interface | USB/RS232/RS485/WiFi/Dry-contact |
Environmental
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
Certifications: IEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, 61000-3-12
FAQs
What are the main performance specifications of the Axpert MAX TRI inverter?
The Axpert MAX TRI inverter has a capacity of 12000VA/12000W with a peak efficiency of 93%. It operates at a voltage of 230 VAC and offers a surge power of 24000VA.
Is the Axpert MAX TRI compatible with different battery types and solar panels?
Yes, the inverter is compatible with a 48 VDC battery system and supports MPPT solar charging with a maximum PV array power of 12000W.
What are the physical specifications of the Axpert MAX TRI?
The physical dimensions and weight of the Axpert MAX TRI are not specified in the provided data. Please refer to the product manual for detailed information.
What are the installation requirements for the Axpert MAX TRI?
The Axpert MAX TRI can be installed in parallel with up to 6 units. It requires a voltage range of 170-280 VAC for personal computers and supports both 50 Hz and 60 Hz frequency ranges.
What warranty is provided with the Axpert MAX TRI inverter?
Warranty information is not specified in the provided data. Please contact Voltronic Power or your distributor for detailed warranty terms.
What certifications and standards does the Axpert MAX TRI comply with?
The Axpert MAX TRI is certified under IEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, and 61000-3-12 standards.
What are the operating conditions for the Axpert MAX TRI?
Specific operating conditions such as temperature and humidity are not detailed in the provided data. Please refer to the product manual for environmental specifications.
What are the key features and benefits of the Axpert MAX TRI?
Key features include pure sine wave output, auto-sensing frequency, and the ability to operate in parallel with up to 6 units, making it highly versatile for various applications.
