Voltronic Power Axpert MAX III 12KW
Voltronic Power Axpert MAX III 12KW
The Axpert MAX III by Voltronic Power is a high-performance inverter designed to meet your power needs with precision. Featuring a 230VAC output and a robust 24000VA surge power capacity, this inverter ensures reliable operation across a wide voltage range and auto-sensing frequency capabilities. Ideal for both residential and commercial applications, the Axpert MAX III is perfect for powering personal computers, home appliances, and sensitive electronic equipment.
Key Features
- User-friendly LCD setting and intuitive — User-friendly LCD setting and intuitive LED design
- Grid support and built-in CT — Grid support and built-in CT sensor
- Built-in DC, AC breaker, PV — Built-in DC, AC breaker, PV DC switch
- Easy access cable design with — Easy access cable design with sliding door
- Dual inputs and Dual outputs — Dual inputs and Dual outputs for smart energy management
- New wall mount bracket design
- Upgrade maximum PV power to — Upgrade maximum PV power to 12000W or 18000W
- Parallel operation with 6 units
- User Selectable Hybrid or Off-Grid — User Selectable Hybrid or Off-Grid mode inverter operation
Specifications
Electrical
| Voltage | 230 VAC |
| Selectable Voltage Range | 90-280 VAC (For Home Appliances) |
| Frequency Range | 50 Hz/60 Hz (Auto sensing) |
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
| Surge Power | 24000VA |
| Efficiency (Peak) | 93% |
| Transfer Time | 15 ms (For Personal Computers), 20 ms (For Home Appliances) |
| Waveform | Pure sine wave |
| No Load Power Consumption | <75W |
| DC Voltage | 12 VDC ± 5%, 100W |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Overcharge Protection | 66 VDC |
| Solar Charger type | MPPT |
| Maximum PV Array Power | 18000W (Max. 12000W per tracker) |
| MPP Range @ Operating Voltage | 90 ~ 450 VDC |
| Maximum PV Array Open Circuit Voltage | 500 VDC |
| Maximum PV Input Current | 40A/27A (MAX 60A) |
| Maximum Solar Charge Current | 200A |
| Maximum AC Charge Current | 200A |
| Maximum Charge Current | 200A |
| Compliance Safety | IEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, 61000-3-12 |
Mechanical
| Dimension, D x W x H (mm) | 176.3 x 432.4 x 687 |
| Net Weight (kgs) | 28.5 |
| Communication Interface | USB/RS232/RS485/Wifi/Dry-contact |
Environmental
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -15°C to 60°C |
Certifications: IEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, 61000-3-12
FAQs
What are the main performance specifications of the Axpert MAX III?
The Axpert MAX III inverter operates at a voltage of 230 VAC with a selectable range of 170-280 VAC for personal computers. It offers a peak efficiency of 93% and a surge power capacity of 24000VA.
Is the Axpert MAX III compatible with different battery types and solar panels?
Yes, the Axpert MAX III is compatible with a 48 VDC battery system and supports solar panels with a maximum PV array power of 18000W, utilizing an MPPT solar charger.
What are the physical specifications of the Axpert MAX III?
The Axpert MAX III's dimensions and weight are not specified in the provided details. However, it is designed for robust performance and ease of installation.
What are the installation requirements for the Axpert MAX III?
Installation of the Axpert MAX III should be performed by a qualified technician, ensuring proper connection to the battery and solar panels, and adherence to local electrical codes.
What warranty is provided with the Axpert MAX III?
The Axpert MAX III typically comes with a manufacturer's warranty, but specific terms and duration should be confirmed with the retailer or distributor.
What certifications and standards does the Axpert MAX III meet?
The Axpert MAX III is certified under IEC 62109, IEC 61683, EN/IEC 61000-6-2, 61000-6-4, 61000-3-11, and 61000-3-12, ensuring compliance with international safety and performance standards.
What are the operating conditions for the Axpert MAX III?
The Axpert MAX III is designed to operate efficiently within a wide range of temperatures and humidity levels, though specific values are not provided in the specifications.
What are the key features and benefits of the Axpert MAX III?
Key features of the Axpert MAX III include its pure sine wave output, high surge power capacity, and efficient MPPT solar charging, making it ideal for both personal computers and home appliances.
