Voltronic Power Axpert MAX E Duplex 11K
Voltronic Power Axpert MAX E Duplex 11K
The Axpert MAX E Duplex 11K by Voltronic Power is a high-performance inverter designed for optimal energy conversion. With precise AC voltage regulation and impressive surge power, it ensures reliable power delivery for various applications. Ideal for residential and commercial solar systems, backup power solutions, and off-grid applications requiring efficient energy management.
Key Features
- Two independent AC power sources — Two independent AC power sources connected and switched automatically
- Adjustable charging current setting for — Adjustable charging current setting for two different power sources via LCD operation and mobile APP
- Status indication with RGB lights
- Maximum PV input current increases — Maximum PV input current increases to 27A
- Built-in Wi-Fi for mobile monitoring — Built-in Wi-Fi for mobile monitoring (Android/iOS App is available)
- Supports USB On-the-Go function
- Replaceable fan design for ease — Replaceable fan design for ease of maintenance
- Battery independent design
- Configurable AC/PV output usage timer — Configurable AC/PV output usage timer and prioritization
- Selectable input voltage range for — Selectable input voltage range for home appliances and personal computers
- Built-in anti-dust kit
- Parallel operation with 6 units
Specifications
Electrical
| Circulation Current under No Load Condition | Max 2A |
| Efficiency (Line Mode) | >95% (Rated R load, battery full charged) |
| High Loss Frequency | 65±1Hz |
| High Loss Return Frequency | 63±1Hz |
| High Loss Return Voltage | 270Vac±7V |
| High Loss Voltage | 280Vac±7V |
| Low Loss Frequency | 40±1Hz |
| Low Loss Return Frequency | 42±1Hz |
| Low Loss Return Voltage | 180Vac±7V (UPS); 100Vac±7V (Appliances) |
| Low Loss Voltage | 170Vac±7V (UPS) 90Vac±7V (Appliances) |
| Max AC Input Current | 60A |
| Max AC Input Voltage | 300Vac |
| Max. Charging Current | 150A |
| Max. Input Current | 27A x 2 (MAX 40A) |
| Max. PV Array Open Circuit Voltage | 500Vdc |
| Nominal Input Frequency | 50Hz/60Hz (Auto detection) |
| Nominal Input Voltage | 230Vac |
| Output Short Circuit Protection | Line mode: Circuit Breaker (70A) Battery mode: Electronic Circuits |
| PV Array MPPT Voltage Range | 90Vdc 450Vdc |
| Parallel Kit | YES |
| Parallel communication | CAN |
| Power Unbalance Ratio | <5% 100% Load |
| Transfer time in parallel mode | Max 50ms |
| Max parallel numbers | 6 |
| DC Offset | ≤100mV |
| High DC Cut-off Voltage | 63Vdc |
| High DC Recovery Voltage | 61Vdc |
| Peak Efficiency | 93% |
| Charging Current | 150A UPS |
| DC Voltage | DC Offset ≦100mV Power Limitation 55Vdc |
| Efficiency | >95% ( Rated R load Line Mode |
| Floating Charging Voltage | 54Vdc |
| Input Voltage Waveform | Sinusoidal (utility or generator) Nominal |
| Output Frequency | 60Hz or 50Hz Peak |
| Output Voltage Regulation | 230Vac± 5% |
| Overcharge Protection | 63Vdc Charging Algorithm 3-Step Charging Curve Time |
| Overload Protection | Surge |
| Rated Output Power | 11000W |
| Rated Power | 11000W Max. PV Array Open Circuit |
| Safety Certification | CE |
| Start-up Voltage | 80V +/- 5Vdc Power Limitation PV Current MPPT temperature 75° 80° |
| Transfer Time | 10ms typical (UPS); |
| AC Voltage Regulation (Batt. Mode) | 230VAC ± 5% |
| Surge Power | 22000VA |
| Efficiency (Peak) | 93% |
| Waveform | Pure sine wave |
| Battery Voltage | 48 VDC |
| Floating Charge Voltage | 54 VDC |
| Maximum PV Array Power | 11000W (5500W x 2) |
| MPPT Range @ Operating Voltage | 90 – 450 VDC |
| Maximum PV Array Open Circuit Voltage | 500 VDC |
| Maximum PV Input Current | 27A x 2(MAX 40A) |
| Maximum Solar Charge Current | 150A |
| Maximum AC Charge Current | 150A |
| Maximum Charge Current | 150A |
| Communication Interface | USB/RS232/RS485/WiFi/Dry-contact |
| Compliance Safety | CE |
Mechanical
| Dimension, D x W x H (mm) | 147.4 x 432.5 x 553.6 |
| Net Weight (kgs) | 18.4 |
Environmental
| Humidity | 5% to 95% |
| Operating Temperature Range | -10°C to 50°C |
| Storage temperature | -15°C~ 60°C |
| Operating Temperature | -10°C to 50°C |
Certifications: CE
FAQs
What are the main performance specifications of the Axpert MAX E Duplex 11K?
The Axpert MAX E Duplex 11K offers a peak efficiency of 93% and can handle a surge power of 22000VA. It regulates AC voltage at 230VAC ± 5% in battery mode.
Is the Axpert MAX E Duplex 11K compatible with all battery types?
The inverter is designed for a 48 VDC battery system, making it compatible with most lead-acid and lithium-ion batteries that match this voltage.
What are the physical specifications of the Axpert MAX E Duplex 11K?
Currently, the specific dimensions and weight of the Axpert MAX E Duplex 11K are not provided. Please refer to the product manual or contact Voltronic Power for detailed physical specifications.
What are the installation requirements for the Axpert MAX E Duplex 11K?
Installation should be performed by a qualified technician. Ensure proper ventilation and avoid exposure to direct sunlight or moisture to maintain optimal performance.
What warranty does Voltronic Power offer for the Axpert MAX E Duplex 11K?
Voltronic Power typically offers a standard warranty for their products, but specific terms for the Axpert MAX E Duplex 11K should be confirmed with the retailer or manufacturer.
What certifications does the Axpert MAX E Duplex 11K have?
The Axpert MAX E Duplex 11K is CE certified, ensuring it meets European safety, health, and environmental protection standards.
What are the operating conditions for the Axpert MAX E Duplex 11K?
The inverter is designed to operate efficiently in a range of environmental conditions, but specific temperature and humidity ranges are not detailed in the provided specifications.
What are the key features and benefits of the Axpert MAX E Duplex 11K?
Key features include a pure sine wave output, a high maximum PV array power of 11000W, and a fast transfer time of 10 ms for personal computers, ensuring reliable and efficient power management.
