Voltronic Power Ara Line Interactive Sinewave Gaming UPS
Voltronic Power Ara Line Interactive Sinewave Gaming UPS
The Ara Line Interactive Sinewave Gaming UPS by Voltronic Power is engineered to provide seamless power protection for gaming setups. With versatile voltage options and precise AC voltage regulation, it ensures your gaming experience remains uninterrupted. Ideal for gaming consoles, high-performance PCs, and home entertainment systems, the Ara UPS delivers reliable power backup and protection against voltage fluctuations.
Key Features
- Provides real-time CPU temperature, CPU — Provides real-time CPU temperature, CPU speed and CPU load level
- Customized RGB lighting for UPS — Customized RGB lighting for UPS status
- Docking LCD design with Bluetooth — Docking LCD design with Bluetooth communication
- Remote LCD panel is built-in — Remote LCD panel is built-in 900mAH battery for 12-hour operating time
- Pure sine wave output
- Built-in AVR for voltage stabilization
- Built-in two USB charger ports — Built-in two USB charger ports for mobile devices
- Provides battery backup and surge — Provides battery backup and surge protected outputs
- Easy replaceable battery design
- Built-in USB com. port and — Built-in USB com. port and RJ-45 network surge protection
- Optional coax surge protection for — Optional coax surge protection for TV antenna
Specifications
Electrical
| Voltage | 110/120 VAC or 220/230/240 VAC |
| Voltage Range | 81-132VAC/86-142VAC or 170-280VAC |
| AC Voltage Regulation (Batt. Mode) | ±10% |
| Frequency Range (Batt. Mode) | 50/60 Hz ±1 Hz |
| Transfer Time | 6ms typical, 10ms max |
| Waveform (Batt. Mode) | Pure Sine Wave |
| Typical Recharge Time | 6-8 hours recover to 90% capacity |
| LCD Display | Input/output voltage, input/output frequency, load in VA/Watts, battery capacity, estimated remaining runtime, site wiring fault indications |
| USB Charger Ports | Type C x 1 & Type A x 1 |
| Output Voltage | 5.2V±5% |
| Load Current | 3A(MAX) |
| USB Port | Supports Windows®, Linux and MAC |
| Compliance & Standards | 110/120VAC model: cTUVus (standard:UL 1778), FCC Part 15 Class B, ENERGY STAR (USA) 220/230/240VAC model: CE , EN 62040-1:2008/A1:2013, IEC 62040-1:2008/A1:2013 |
Mechanical
| Dimension, D x W x H (mm) | 308 x 99 x 280 / 430 x 99 x 280 |
| Net Weight (kgs) | 9.2 / 13.8 |
| Weight | 9.2 / 13.8 |
Environmental
| Humidity | 0-90 % RH @ 0- 40°C (Non-condensing) |
| Noise Level | Less than 40dB / Less than 45dB |
Certifications: cTUVus, UL 1778, FCC Part 15 Class B, ENERGY STAR, CE, EN 62040-1:2008/A1:2013, IEC 62040-1:2008/A1:2013
FAQs
What are the main performance specifications of the Ara Line Interactive Sinewave Gaming UPS?
The Ara UPS offers a voltage range of 110/120 VAC or 220/230/240 VAC with an AC voltage regulation of ±10% in battery mode. It provides a pure sine wave output with a frequency range of 50/60 Hz ±1 Hz and a typical transfer time of 6ms.
Is the UPS compatible with different battery types or solar panels?
The UPS is equipped with a 12 V/9 Ah battery and is not designed for direct integration with solar panels. It is optimized for use with grid power.
What are the physical dimensions and weight of the UPS?
The UPS measures 308 x 99 x 280 mm and has a net weight of 9.2 kg. It does not have an IP rating, indicating it is intended for indoor use.
What are the installation requirements for the UPS?
The UPS should be installed in a well-ventilated area with a stable power supply. Ensure that the input voltage matches the UPS's voltage specifications.
What warranty does Voltronic Power offer for this UPS?
Voltronic Power typically offers a standard warranty period for its UPS products, which covers defects in materials and workmanship. Please check with your retailer for specific warranty terms.
What certifications and standards does the UPS comply with?
The UPS is certified under cTUVus, UL 1778, FCC Part 15 Class B, ENERGY STAR, CE, EN 62040-1:2008/A1:2013, and IEC 62040-1:2008/A1:2013, ensuring compliance with international safety and efficiency standards.
What are the recommended operating conditions for the UPS?
The UPS should be operated in an environment with a temperature range of 0°C to 40°C and a relative humidity of 0% to 90% non-condensing.
What are the key features and benefits of this UPS?
Key features include a pure sine wave output, fast transfer time, and an informative LCD display showing input/output voltage, frequency, load, battery capacity, and estimated runtime. It also includes USB charging ports for added convenience.
