Voltronic Power APlus 42U-300
Voltronic Power APlus 42U-300
The APlus 60kW UPS by Voltronic Power is engineered to deliver reliable power protection with a nominal voltage of 3 x 380/400/415 VAC. Its robust design accommodates a wide voltage range of -30% to +20%, ensuring seamless operation in diverse environments. Ideal for data centers, industrial facilities, and critical infrastructure, the APlus 60kW UPS provides stable power with precise voltage regulation.
Key Features
- 60KW single power module in — 60KW single power module in 3U
- N+1 or N+X parallel redundancy — N+1 or N+X parallel redundancy for power guarantee
- Horizontal expansion by 1+1 cabinet — Horizontal expansion by 1+1 cabinet parallel operation, up to 1.2MW
- Hot-swappable modular design decreases MTTR
- High scalability
- Built-in maintenance bypass switch for — Built-in maintenance bypass switch for easy maintenance without interruptible
- High efficiency double conversion online — High efficiency double conversion online UPS
- Flexible battery configuration and adjustable — Flexible battery configuration and adjustable charging current
- High overload capability
- Power walk-in function
- Built-in dynamic password protection
- Built-in ultra communication slot
Specifications
Electrical
| Rated Output Power (VA) | 300kVA |
| Rated Output Power (W) | 300kW |
| Power Module | 60KVA/60KW (PM-60) |
| Max Power Modules | 5 |
| Nominal Voltage | 3 x 380/400/415 VAC (3P+N) |
| Voltage Range | -30% ~ +20% |
| Nominal Frequency | 50/60Hz (Auto Sensing) |
| Frequency Range | 40Hz ~ 70Hz |
| Power Factor | > 0.99 @ 100% Load, >0.98 @ 50% Load |
| Harmonic Distortion (THDi) | <3% @ 100% load |
| Voltage Regulation(Steady state) | ≤± 1% Typical (balanced load) ; ≤± 2% Typical (unbalanced load) |
| Frequency Range(Synchronized) | 46Hz ~ 54Hz or 56Hz ~ 64Hz |
| Overload Capability | 1 hour for ≤ 110%, 10 mins for 111% ~ 125%, 1 min for 126%~150% and 200ms for >150% |
| Harmonic Distortion | ≤2% THD (Linear Load) ; ≤4% THD (Non-linear Load) |
| Efficiency | 96% |
| Maximum Voltage | +/- 240V (12V x 40 Pcs) |
| Minimum Voltage | +/- 192V (12V x 32 Pcs) |
| Floating Charge Voltage | 2.28V / Cell (2.25 ~ 2.33 Selectable) |
| Boost Charge Voltage | 2.35V/Cell |
| Maximum Charging Current (Per Power Module) | 18A (Adjustable) |
| Smart RS-232 / USB | Supports Windows® Family, Linux and MAC |
| Optional SNMP | Power management from SNMP manager and web browser |
| Safety | IEC/EN 62040-1 |
| EMC | IEC/EN 62040-2 Category C3 |
Mechanical
| Cabinet Dimension (D x W x H) mm | 1100x600x2010 |
| Net Weight (Kg) | 516 |
| Weight | 516 |
Environmental
| Operating Temperature | 0 ~ 40°C |
| Relative Humidity | 0 ~ 95% non-condensing |
| Altitude | <1000m for Nominal power |
| IP Protection | IP 20 |
Certifications: IEC/EN 62040-1, IEC/EN 62040-2 Category C3
FAQs
What are the main performance specifications of the APlus 60kW UPS?
The APlus 60kW UPS offers a high efficiency of 96% and operates with a nominal voltage of 3 x 380/400/415 VAC (3P+N). It maintains a power factor of >0.99 at full load and harmonic distortion of less than 3% at 100% load.
Is the APlus 60kW UPS compatible with different battery types or solar panels?
The UPS supports a nominal voltage range of +/- 192V to +/- 240V, making it compatible with various battery configurations. However, it does not directly support solar panels without additional equipment.
What are the physical specifications of the APlus 60kW UPS?
The specific dimensions and weight of the APlus 60kW UPS are not provided in the key specifications. Please refer to the product manual or contact Voltronic Power for detailed physical specifications.
What are the installation requirements for the APlus 60kW UPS?
Installation should be performed by a qualified technician. Ensure the UPS is installed in a well-ventilated area with adequate space for maintenance and airflow.
What warranty is provided with the APlus 60kW UPS?
Voltronic Power typically offers a standard warranty for their UPS products. For specific warranty details, please consult the product documentation or contact Voltronic Power directly.
What certifications and standards does the APlus 60kW UPS comply with?
The APlus 60kW UPS is certified under IEC/EN 62040-1 and IEC/EN 62040-2 Category C3, ensuring compliance with international safety and performance standards.
What are the operating conditions for the APlus 60kW UPS?
The UPS is designed to operate efficiently within a wide frequency range of 40Hz to 70Hz. For optimal performance, it should be used in environments with controlled temperature and humidity levels.
What are the key features and benefits of the APlus 60kW UPS?
Key features of the APlus 60kW UPS include high efficiency, low harmonic distortion, and robust overload capability. These features ensure reliable power protection and energy savings.
